Applicable Fibers

SM(G.652/G.657), MM(G.651), DS(G.653), NZDS(G.655), EDF, BIF/UBIF

Applicable Fiber Core

Single core

Fiber Diameter

Cladding diameter 80-150μm, Coating Diameter 100-1000μm

Fusion Splice Model

Prestore: 40 Groups; User Define: 80 Groups

Average Fusion Splice Loss

0.02dB(SM), 0.01dB(MM), 0.04dB(DS), 0.04dB(NZDS)

Echo Loss

Better then 60dB

Splice Duration Time

9sec (typical parameter); 7sec (fast mode)

≥2N(Optional Big Rally fusion splicer 8N)

X&Y: 180 times; X/Y: 350 times

Power Supply

11.1V Lithium battery, 13.5V/5A power adapter

Battery

6800mAh Li-Battery. Typically work 260 times (fusion splicing/heating), single battery charge 3hours, can be recycled 500 times.

Splice Result Storage

10,000 groups of the latest records

Data Interface

USB2.0

Operating Enviroment

Altitude: 0～5000m; relative humidity: <95%; temperature: -20℃~55℃; maximum wind speed: 15m/s

Storage Enviroment

Relative humidity: <95%; temperature: -40℃~80℃ (except battery);

Weight of equipment

1.89kg (include battery)

Size/Weight

166D x 142W x 139H (mm) / 1.53kg(1.93 with battery)

Applicable Fiber Cable Diameter

2mm, 3mm, 4mm, 6mm

Heating Time

Fusion-protection sleeve 9s fast heating (customizable)

Heating Temperature

Below 300°C (customizable)
