* Up to 28Gb/s bi-directional data links
* Hot-pluggable SFP+ footprint
* Built-in digital diagnostic functions
* Oxide VCSEL/EML/DFB transmitter
* Compliant with single lane 100G Ethernet applications
* Duplex LC connector
* Up to 40 km on 9/125μm SMF,100m(150m) over M5F MMF (50/125μm Om4), 70m(100m) over M5E MMF (50/125μm OM3)
* Single +3.3V power supply operating
* TX input and RX output CDR retiming
* Temperature range 0°C to 70°C
* RoHS-6 Compliant
25Gb/s Transceivers
|
P/N |
Package |
Distance |
Wavelength |
Source |
Fiber |
Output Power |
Sensitivity |
| HSV3001D | SFP28 | 100m | 850nm | VCSEL | MM | -8.4 ～2.4dBm | ≦-10.3dBm |
| HSV3010D | SFP28 | 10km | 1310nm | DFB | SM | -4.3 ～ 4.5dBm | ≦-11.3dBm |
| HSV3040D | SFP28 | 40km | LWDM | EML | SM | -3.0 ～3.3dBm | ≦-16dBm |
